UL LISTED ADDREASSABLE FIRE ALARM SYSTEM

Our Brand have been engaged in fire security for over 15yrs by providing a variety of residential, commericial and industrial fire security solution, they ‘re now also providing OEM & ODM services for Schneider, Bosch, Siemens, etc.

Our offered brand has complete solution for Analog addressable fire detection alarm system, all devices are UL listed, supports 1 Loop Panel x 127 addressable devices I 2 Loops Panel x 254 addressable devices + 40 configurable zones by each loop, each device can be addressed and can be assigned to unique address to one of 40 zones, users can easily figure out when and where the fire breaks out. In addition, our fire system is with self-test function and installed followed by NFPA 72, very practical and easy to install.

 • 32 bit processor Arm Cortex M3

• High/Low voltage separately protection circuit for safety

• Pluggable Loop PCB board available

• Networking up to 64 panels

• AC type detector integration available by I/O module 621

• Loop Options: 1 loop; 1 loop expanded to 2-loops; 2-loops

• High contrast backlit LCD provides 4 rows of 40 characters

for device and system status

• 4 Access Levels & 4000 events history log

• Day/night mode configurable

• Support 1 loop panel x 127 addressable devices & 2 Loop panel x 254 addressable devices + 40 configurable zones/each loop

• Automatic device type-code verification
